Rheem
RTCH022TK Rheem Pool Chiller Heat Pump
RTCH022TK Rheem Pool Chiller Heat Pump
SKU RTCH022TK
RTCH022TK-DQV-1 Specification Top discharge model. It operates on 380-415V three phase power, delivers a nominal cooling capacity of 21.88 kW, has a COP of 4.39, uses R407C refrigerant, and features a dual-fan top discharge cabinet measuring 1536 × 617 × 983 mm. It requires 2.5 metres of overhead clearance for airflow. RTCH022TK-DQH-1 - This model has the same performance and electrical specifications as the DQV model. The only difference is the cabinet design. The DQH features a side discharge airflow configuration and measures 1536 × 639 × 957 mm, making it slightly wider and lower. It requires only 350 mm overhead clearance, but needs 2.5 metres of clearance in front of the fan discharge.
RTCH022TK-DQV-1: Customer specification sheet for the top discharge model.
RTCH022TK-DQH-1: Customer specification sheet for the side discharge model.
Product Compatibility
Product Compatibility
Package Dimensions
Package Dimensions
L x W x H
Unit Type
Unit Type
Shipping
Shipping
We use Australia Post express post for all deliveries, with a tracking number.
See Terms & Conditions for more information
